Forestoad 10 Quart Hydraulic Power Unit Single Acting 12V/DC Hydraulic Pump for Dump Trailer Car Lifting, SAE#6 Connector,2 GPM Flow Rate, 3200 PSI Max Relief Pressure, Metal Reservoir 2.5 Gal

Informação Básica

Lugar de origem:	China Ningbo
Marca:	Forestoad
Certificação:	CE,ISO
Número do modelo:	Floresta TD-DL

Quantidade de ordem mínima:	20 unidades
Preço:	259
Detalhes da embalagem:	Embalados em caixas de cartão, e depois em paletes de madeira.
Tempo de entrega:	15 dias úteis
Termos de pagamento:	T/T, União Ocidental, L/C
Habilidade da fonte:	2.000 unidades por mês

Melhor preço contacto

Tampa de plástico para motor:	SIM. MC-02	Tanque:	4L a 18L, aço ou plástico, horizontal ou vertical
Portas:	SAE6#	Motor:	12V, 1600W, 2800 rpm, S3 Duty.
Bomba de engrenagem:	1.6cc/r 2.1cc/r 2.5cc/r 3.2cc/r	Pressão da válvula de alívio:	180BAR
Remoto e cabo:	2 botões, 3 fios, 4 metros com conector rápido	Válvula Solenóide:	12VDC 18W Bobina
Embalagem:	Um pacote de energia em uma caixa e depois paletes	Peso:	Cerca de 15-18kgs/pc com cada pacote de energia
Destacar:	10 quart hydraulic power unit , 12V DC hydraulic pump for dump trailer , single acting hydraulic pump 3200 PSI

Forestoad 10 Quart Hydraulic Power Unit

This single acting 12V/DC hydraulic pump is engineered for dump trailers, car lifting systems, and various industrial lifting applications. Featuring SAE#6 connectors, 2 GPM flow rate, and 3200 PSI maximum relief pressure with a durable 2.5-gallon metal reservoir.

Product Overview

High-pressure double acting hydraulic power pack specifically designed for tipper trailers and demanding lifting applications requiring reliable performance and durability.

Key Components

High pressure gear pump
DC motor for consistent power delivery
Aluminum center manifold
Check valve for system safety
Relief valve for pressure control
Solenoid release valve
Hydraulic oil tank

Operation

Simple two-button control: Push "UP" button to activate DC motor and lift the trailer. Push "DN" button to engage solenoid valve and DC motor for controlled lowering.

Applications

Ideal for tipper trailers, fork lifts, scissor lifts, and other single acting lift systems requiring reliable hydraulic power.

Technical Specifications

Feature	Specification
Plastic Cover for Motor	YES (MC-02)
Tank Options	4L to 18L, Steel or Plastic, horizontal or vertical
Ports	GSAE6#
Motor	12V, 1600W, 2850 RPM, S3 Duty
Gear Pump	2.1cc/r
Relief Valve Pressure	220Bar
Remote and Cable	2 Buttons, 3 lines, 4 meters
Solenoid Valve	12VDC 18W coil
Packing	One power pack per box, palletized
Weight	Approximately 15-18kg per unit

Pricing: From USD $125.00 to $185.00 per unit (includes motor, pump, tank, manifold, valves, remote and cable, plastic cover)

Product Drawings

180 Bar High Pressure Hydraulic Power Pack Diagram

Hydraulic Power Pack Schematics

Hydraulic Power Pack Technical Schematics

Packing Information

Unit weight approximately 15-18kg (varies based on specifications, tank type, and component selection).
